Union 50mm DADEX PPRc

Description

Union 50mm



DADEX PPRc pipes and fittings local ,, Food Grade, Plumbing Materials, Suppliers in Islamabad Pakistan Contact 0322-3540656



What is Union 50mm DADEX PPRc ?



A PPR-C union is a pipe fitting used to connect and disconnect two PPR (Polypropylene Random Copolymer) pipes (50 mm) without cutting the pipeline. The “union” design includes a nut + O-ring gasket that enables easy assembly/disassembly for maintenance or replacement.
“PN25” refers to its pressure class — rated for up to 25 bar at standard temperature conditions.

💡 PPR-C material is widely used in plumbing, HVAC, and hot & cold water systems due to its chemical resistance, durability, and long service life.

---

📋 Description & Specifications

Material & Build

• Material: Polypropylene Random Copolymer (PPR-C) — high quality polymer that resists corrosion, scaling, and chemical effects.

• Color: Typically green (industry color for PPR hot/cold water systems).

• Gasket: Rubber O-ring for leak-proof seal.

• Union Nut: Usually plastic or reinforced PPR.

Size & Rating

• Nominal Size: 50 mm (for pipes with 50 mm outer diameter).

• Pressure Rating: PN25 — up to 25 bar at ~20 °C (pressure decreases with higher temperatures).

• Temperature Range: Approximately -20 °C up to about 95 °C (continuous hot water typical up to ~70 °C).

Standards

• Often manufactured to DIN 8077/8078, ISO 15874 or similar industry standards covering PPR pipe systems.

• Suitable for potable water and HVAC applications.

---

📦 Typical Applications

Hot & Cold Water Supply

• Domestic and commercial hot & cold water plumbing.

• Hot water distribution in kitchens, bathrooms, and service areas.

• Cold potable water lines in buildings.

HVAC Systems

• Connection of risers to pumps, valves, and manifolds.

• Branch lines in hydronic heating/cooling loops.

• Easy disconnection for cleaning heat exchangers or servicing pumps.

Other Uses

• Industrial chilled water circuits.

• Solar water heater connections.

• Systems requiring regular maintenance access.

---

📐 Why Use a Union Instead of a Fixed Joint?

Benefits:
✔️ Easy Disassembly — can remove sections without cutting pipe.
✔️ Maintenance-Friendly — ideal where valves, filters, or pumps might need service.
✔️ Durable & Leak-Resistant — PPR materials are corrosion-proof and resistant to scaling.
✔️ Suitable for High Pressure & Temperature — PN25 rating ensures use in higher temperature hot water and HVAC circuits.

---

🔧 Installation: Step-by-Step

Tools you’ll need:
PPR welding machine (socket fusion tool), pipe cutter, measuring tape, marker, cleaning cloth.

1. Preparation

1. Cut the Pipe — cut ends cleanly at 90° with a pipe cutter; remove burrs.

2. Clean the Pipe & Fitting — wipe off dust and moisture.

2. Heating & Welding

1. Preheat Tool: Set the socket fusion machine to the recommended temperature (often around 260 °C).

2. Insert Pipe & Fitting: Insert pipe end into the union socket and hold straight.

3. Heat Fusion: Hold both pipe and fitting against heated tool until proper heating time is reached (follow manufacturer’s fusion chart).

4. Join & Hold: Quickly insert pipe into the union socket and hold until joint cools and solidifies.

3. Union Assembly

1. Ensure Gasket Present: Check union O-ring/gasket is in place and clean.

2. Fit Pipes Together: Align both PPR pipe ends fitted with union halves.

3. Tighten Nut: Hand-tighten the union nut; do not over-tighten — ensure comfortable seal without deforming parts.

4. Testing

• Water-pressure test after installation to check for leaks under working pressure.

Tips:

• Always follow specific manufacturer instructions.

• Avoid mechanical stress near the joint during cooling.

---

🚰 Performance & Safety

• Leak-proof: With proper fusion and gasket, union ensures tightness.

• Corrosion-Free: PPR does not rust or scale like metals.

• Long Life: Over 50 years expected lifespan under normal conditions.

• Safe for Drinking Water: Meets potable water standards when certified.

---
